Yuav Ua Npog Rau Qhov Cuam Tshuam Hluav Taws Xob Chav Boiler

DZL Thev-ciav hluav taws chav boiler
Qauv: DZL Series
Tus nqi zog: 6T-15T
Chav Siab: 1.25Mpa-2.5Mpa (Xaiv tau raws li qhov xav tau)
Chav Kub: 100 ℃ - 226 ℃
Roj: Sawdust, Biomass Pallet, Husks Hnyuv, Cov Txiv Laum Quav, Cov Quav Quav, Cov Quav Quav, Cov Quav Pob Kws, Cov Pob Kws, Cov Hniav, xyoob suav, Kab thiab lwm yam roj rau cov qoob loo.
Daim Ntawv Thov: Khaub Ncaws Ntxuav Thiab Ironing, Biochemical, Khoom Noj Thiab Dej Haus Chav Ua Noj, Lub Tsev Vaj Tse, Kev Ua Npuas Ncauj Yas, Ua Npuas Ncauj Ntoo, thiab lwm yam.

Khoom Taw qhia

Nta

Chain Grate Chav Boilerrealizes ib lub boiler rau ntau lub hom phiaj, nrog lub suab nrov ua haujlwm tsawg, txuag hluav taws xob thiab kev tiv thaiv ib puag ncig, kev pab lub neej ntev, kev ua haujlwm siab, kev nyab xeeb thiab kev ntseeg tau.Nws kub zoo nyob sab hauv thiab tsis tawm cov pa luam yeeb dub, tsim kom huv thiab ua haujlwm zoo rau ib puag ncig. rau koj.Nws adopts desulfurization zoo thiab hmoov av tshem tawm cuab yeej, muaj txiaj ntsig zoo rau kev tiv thaiv ib puag ncig thiab txuag hluav taws xob.

Saw Grate Chav Boilerhas cov yam ntxwv ntawm kev tiv thaiv ib puag ncig, kev nyab xeeb thiab txuag hluav taws xob. Yooj yim rau nruab thiab txav chaw, nws tuaj yeem txuag ntau lub peev txheej. Tsis tas li, nws cov qauv muaj kev tiv thaiv zoo rau corrosion, zoo heev thiab ruaj khov.

Khoom Daim Ntawv Qhia

Cov tsis

Qauv	Nyob evaporation Peev Xwm (t/h)	Rated siab (MPa)	Chav sov (℃)	Kev ntsuas kom sov ua tau zoo (%)	Kev siv roj (kg / teev)	Qhov ntev L×W×H (m)	Ceeb thawj (t)
DZL1-1.25-AII	1	1.25	194/204	≥83	176.6	5.1×2.2×2.9	15
DZL2-1.25-AII	2	1.25	194/204	≥83	352.3	6.14×2.6×3.3	18
DZL3-1.25 / 1.6-AII	3	1.25/1.6	194/204	≥83	522	6.33×2.7×3.3	24
DZL4-1.25 / 1.6-AII	4	1.25/1.6	194/204	≥83	571	6.88×2.7×3.3	27
DZL6-1.25 / 1.6-AII	6	1.25/1.6	194/204	≥83	1044	7.29×3.2×3.7	31
DZL8-1.25 / 1.6-AII	8	1.25/1.6	194/204	≥83	1396.5	7.8×3.4×3.7	33
DZL10-1.25 / 1.6-AII	10	1.25/1.6	194/204	≥83	1743.3	8.5×3.4×3.7	41

Cov khoom lag luam zoo

1. High efficiency, tus nqi qis
(1) Membrane phab ntsa dej yeeb nkab kev teeb tsa kom thaj chaw kom sov ntau dua thiab txhim kho cov thermal txuag
(2) Lub zog txuag hluav taws xob tau teeb tsa rau tom qab kom siab nqus cov cua sov pov tseg thiab txuag nqi
2. Muaj kev ruaj ntseg siablag luam
(1) PLC ntse tswj lub cev tuaj yeem paub txog kev ua haujlwm tsis siv neeg ntawm kev them nyiaj, ua haujlwm ua haujlwm, pib kiv cua thiab nres, dej tso, slag tawm, thiab lwm yam, nws tseem muaj kev tiv thaiv kev tiv thaiv kev ua haujlwm xws li overpressure, overtemperature, dej tsis txaus, dej xau, lub cev muaj zog sib tshooj, lwm yam.
(2) Teeb ntau qhov kev tiv thaiv kev nyab xeeb, ntsuas kev nyab xeeb, ntsuas dej ntawm lub tswb ntim,
siab ntsuas ntsuas, ntsuas siab, thiab lwm yam kom ua haujlwm zoo
3. Kev nyab xeeb tshwj xeebtsim
(1) Lub nruas boiler muaj qhov ua nrog txwv tsis pub muaj dej tsis tshua hnov zoo txog kev nyab xeeb
ntaus ntawv, uas tuaj yeem ncaj qha nrhiav cov qib dej hauv lub cub tawg, thiab tsis muaj dej tsis muaj dej txaus.
(2) Lub cev rhawv lub cev txais cov txheej txheem kev kho cua sov kom tshem tawm cov kev ntxhov siab steel thiab ua haujlwm yam tsis muaj teeb meem
4. Tsheb thauj mus los yooj yim
Lub rhaub dej thiab lub tshuab pabcuam pabcuam tau sib sau ua ke tus qauv, lub sijhawm nruab yog lub sijhawm luv, thiab kev nqa thiab kev thauj mus los yooj yim
