Siv dav siv me me Biomass Pellet Chav Generator Nqe

Biomass Chav Generator
Qauv: LSG (Biomass) Series
Chav Peev Xwm: LSG (Biomass) 0.05 - 0.5T/H
Chav Siab: {{0}}.4/0.7Mpa (yeem raws li qhov xav tau)
Fuel:Biomass Particle
Daim ntaub ntawv: Khaub ncaws ntxhua khaub ncaws thiab Ironing, Biochemical, Khoom noj khoom haus thiab dej haus chav tu, tsev khoom tu, yas ua npuas ncauj, ntoo ua, thiab lwm yam.

Khoom Taw qhia

Product Description

Biomass pellet chav generatortseem hu ua chav boiler lossis chav cua sov boiler. Nws yog biomaterial roj raug rho tawm haujlwm boiler.This series ntawm biomass pellet chav generator muaj boiler thiab auxiliary khoom. Lub boiler feem yog ntsug qauv. Nws muaj cov yam ntxwv hauv qab no: cov qauv compact, me me, tsis tshua muaj suab nrov, thaj chaw cua sov loj, thermal efficiency, muaj zog ruaj khov, zoo stability, movable hom, muaj peev xwm mus cuag cov mos los yog tawv kav, yooj yim rau nruab thiab lwm yam.

Daim duab

Khoom Zoo

1. Ceev ncu tiam

Chav yog tsim sai sai (3 - 5 feeb) tom qab lub boiler pib, thiab nws ncav cuag kub thiab siab sai sai.

2. High thermal efficiency

(1) ntsug dej yeeb nkab membrane phab ntsa qauv, nce tshav kub nqus cheeb tsam, txo tshav kub poob, txuag roj.

(2) Nruab nrog lub zog txuag, txhim kho thermal efficiency.

3. Siab - kawg tsis siv neeg tswj qhov system

Lub teb chaws tus qauv hluav taws xob tswj cov khoom siv thiab lub ntiaj teb hom hluav taws xob, tuaj yeem paub txog kev ua haujlwm tsis siv neeg ruaj khov.

4. Kev ruaj ntseg siab

(1) Lub peev xwm dej me me, tsis xav tau kev tshuaj xyuas txhua xyoo

(2) Nruab nrog kev ruaj ntseg interlock ntaus ntawv, xws li dej tsis txaus, overpressure, overtemperature, cua to, lub cev muaj zog overload thiab lwm yam kev tiv thaiv kev ruaj ntseg functions.

5. Kev ntseeg siab

(1) Cov khoom siv tag nrho yog tsim raws li tus qauv ntawm chav boiler loj.

(2) Cov cuab yeej tiv thaiv kev nyab xeeb: kev tswj lub siab, lub tshuab xa hluav taws xob, kev nyab xeeb valve, ntsuas qhov siab, dej qib tswj tsis siv neeg, thiab lwm yam.

6. Cov qauv zoo heev

Cov qauv tsim tshwj xeeb, me me thiab siv tau.

Tech Parameter

LSG Biomass Steam Generator

Qauv	Ratedevaporation muaj peev xwm (t / h)	Rated siab (MPa)	Chav ntsuas kub (degree)	Thermal efficiency (%)	Roj noj (kg / h)	Dimension D×H (m)	Qhov hnyav (t)
LSG0.1 - 0.4	0.1	0.4	151	≥83	18.39	0.81×2.59	0.72
LSG0.2 - 0.4	0.2	0.4	151	≥83	36.23	0.91×2.9	0.98
LSG0.3 - 0.7	0.3	0.4/0.7	151/171	≥83	53.8	1.02×3.2	1.6
LSG0.5 - 0.7	0.5	0.4/0.7	151/171	≥83	89.76	1.32×3.68	2.88
LSG0.7 - 0.7	0.7	0.4/0.7	151/171	≥83	125.1	1.42×3.87	3.67
LSG1 - 0.7	1	0.4/0.7	151/171	≥83	178.7	1.62×4.38	4.8
