Diesel Roj Rhaub Gas Fuel Vertical Steam Generator Fast

Roj/Gas Fast Steam Generator
Qauv: LSS (Oil / Gas) Series
Chav Muaj Peev Xwm: LSS (Oil / Gas) 0.05-0.5T / H
Chav Siab: 0.4 / 0.7Mpa (yeem raws li qhov xav tau)
Roj: Natural gas, liquefied petroleum gas
Daim ntaub ntawv: Khaub ncaws ntxhua khaub ncaws thiab Ironing, Biochemical, Khoom noj khoom haus thiab dej haus chav tu, tsev khoom tu, yas ua npuas ncauj, ntoo ua, thiab lwm yam.

Khoom Taw qhia

Product Description:

Chav generator yog nruab nrog kev nyab xeeb valve, tswj lub siab, tiv thaiv overpressure, tiv thaiv overtemperature, tiv thaiv kev puas tsuaj los ntawm lub tshuab hluav taws xob ntau dhau;

Nyob rau tib lub sij hawm muaj qhov txwv tsis pub muaj kev tiv thaiv dej, nyob rau hauv cov ntaub ntawv ntawm cov dej nres lub tshuab hluav taws xob yuav cia li tsis ua hauj lwm, tiv thaiv lub chav generator qhuav kub los ntawm hluav taws xob cua sov caij puas los yog txawm hlawv tawm tshwm sim.

Kev Tiv Thaiv Kev Tiv Thaiv Ua rau muaj kev nyab xeeb ntawm cov neeg ua haujlwm thiab cov khoom siv tau lees paub ntau dua, txawm tias nyob rau hauv cov ntaub ntawv ntawm lub tshuab hluav taws xob ua haujlwm tsis raug ntawm lub voj voog luv luv, lub boiler leakage yuav txiav tawm Circuit Court, kev tiv thaiv raws sij hawm ntawm cov neeg ua haujlwm thiab cov kab tswj, cov neeg siv tau so assured siv. .

Product Details:

Tech Parameter:

LSS Roj/Gas Chav Generator

Qauv	Rated evaporation Muaj peev xwm (kg / h)	Rated chav siab (Mpa)	Thermal efficiency (％)	Chav kub (℃)	Dimension (m)	Qhov hnyav (t)
LSS0.05-0.4/0.7-Y(Q)	50	0.4/0.7	≥93	151/171	0.62×0.62×0.83	0.206
LSS0.1-0.4/0.7-Y(Q)	100	0.4/0.7	≥93	151/171	0.69×0.69×0.968	0.252
LSS0.15-0.4/0.7-Y(Q)	150	0.4/0.7	≥93	151/171	0.75×0.75×1.13	0.303
LSS0.2-0.4/0.7-Y(Q)	200	0.4/0.7	≥93	151/171	0.8×0.8×1.286	0.35
LSS0.3-0.4/0.7-Y(Q)	300	0.4/0.7	≥93	151/171	0.8×0.8×1.525	0.55
LSS0.4-0.4/0.7-Y(Q)	400	0.4/0.7	≥93	151/171	0.84×0.84×1.775	0.7
