Wns Roj Raug Rho Tawm Haujlwm Chav Boiler Tsum

WNS roj roj / roj nkev tub yees
Qauv: WNS Series
Tus nqi zog: 0.5T-15T
Chav Siab: 0.7Mpa-2.5Mpa (Xaiv tau raws li qhov xav tau)
Roj: Nkev nkev, roj liquefied roj av
Roj: Sawdust, Biomass Pallet, Husks Hnyuv, Cov Txiv Laum Quav, Cov Quav Quav, Cov Quav Quav, Cov Quav Pob Kws, Cov Pob Kws, Cov Hniav, xyoob suav, Kab thiab lwm yam roj rau cov qoob loo.

Khoom Taw qhia

Cov ntawv thov

Roj Roj Roj Muaj Chav Boilerhas siv ntau yam thiab tuaj yeem siv rau hauv kev tsim cov zaub mov tiav, xws li kev kub siab kom tsis muaj kab noj ntawm cov pwm tuaj yeem, kua taum pauv, khoom noj siv mis, thiab lwm yam, thiab tseem tuaj yeem siv rau cua sov, tsev cog khoom cog cog kev lag luam, kev lag luam yug tsiaj, cua kub hauv tsev, thiab lwm yam.

Cov Lus Qhia Paub Khoom

20200707162608ab45918b93b64d1ea7935ad543016aad

Cov tsis

Qauv: WNS Series

Tus nqi zog: 1.0MW-14MW

Chav Siab: 0.4Mpa ~ 2.5Mpa (Raws li cov neeg siv' s yuav tsum tau)

Roj: Nkev, LPG, LNG, CNG, Biogas, Nkev Hauv Nroog, Diesel, Roj Roj, Roj thiab Roj.

Qauv	Nyob evaporationcapacity (t / h)	Nyob steampressure (Mpa)	Chav sov (℃)	Kev ua haujlwm thermal (％)	Kev siv roj		Qhov Loj (m)	Ceeb thawj (t)
Qauv	Nyob evaporationcapacity (t / h)	Nyob steampressure (Mpa)	Chav sov (℃)	Kev ua haujlwm thermal (％)	Roj (kg / teev)	Roj (Nm³ / h)	Qhov Loj (m)	Ceeb thawj (t)
WNS1-0.7 / 1.0-Y (Q)	1	0.7/1.0	194	≥98.36	61	73	3.2×1.9×2.2	4.9
WNS2-1.0 / 1.25-Y (Q)	2	1.0/1.25	194	≥98.36	121	145	4.2×2.3×2.5	8
WNS3-1.0 / 1.25-Y (Q)	3	1.0/1.25	194	≥98.36	182	217	4.5×2.1×2.4	9
WNS4-1.0 / 1.25-Y (Q)	4	1.0/1.25	194	≥98.36	243	289	5.0×2.3×2.6	11
WNS6-1.25 / 1.6-Y (Q)	6	1.25/1.6	194	≥98.36	367	435	5.4×2.4×2.7	18.6
WNS10-1.25 / 1.6-Y (Q)	10	1.25/1.6	194	≥98.36	601	735	6.3×2.7×3.2	20.5
WNS15-1.25 / 1.6-Y (Q)	15	1.25/1.6	194	≥98.36	906	1101	8.9×3.4×3.6	42
WNS20-1.25 / 1.6-Y (Q)	20	1.25/1.6	194	≥98.36	1211	1467	7.8×3.6×4.0	52
