Ntoo ziab 130 Kg/h 0.7 Mpa Chav Generator Hluav Taws Xob

Product Description

LDR hluav taws xob cua sov series ceev chav generator yog ib hom me me ntsug tsis siv neeg cua sov khoom. Nws tuaj yeem ua kom muaj zog sai sai (li 3 ~ 5 feeb) thiab muaj kev ua haujlwm siab thermal. Nws muaj cov qauv yeeb nkab ntsug, ntim dej me me, kev nyab xeeb thiab tsis xav tau kev tshuaj xyuas txhua xyoo. Tag nrho cov khoom siv tuaj yeem tsim cov chav tsuas yog los ntawm kev sib txuas cov dej thiab cov khoom siv hluav taws xob.

Daim duab

Technical Parameter

LDR Electric Steam Generator

Qauv	Rated evaporation Muaj peev xwm (kg / h)	Rated chav siab (Mpa)	Rated fais fab tuag (kw)	Thermal efficiency (％)	Chav ntsuas kub (degree)	Dimension (m)	Qhov hnyav (t)
LDR0 008-0.4	8	0.4	6	Ntau dua lossis sib npaug li 99	151	0.82×0.84×0.8	0.12
LDR0 012-0.4	12	0.4	9	Ntau dua lossis sib npaug li 99	151	0.82×0.84×0.8	0.123
LDR0 016-0.4	16	0.4	12	Ntau dua lossis sib npaug li 99	151	0.82×0.84×1	0.139
LDR0 024-0.4	24	0.4	18	Ntau dua lossis sib npaug li 99	151	0.82×0.84×1	0.14
LDR0 032-0.4	32	0.4	24	Ntau dua lossis sib npaug li 99	151	0.82×0.84×1.2	0.142
LDR0 065-0.4	65	0.4	48	Ntau dua lossis sib npaug li 99	151	0.82×0.84×1.4	0.146
LDR0 075-0.4	75	0.4	54	Ntau dua lossis sib npaug li 99	151	0.82×0.84×1.4	0.15
LDR0 1-0.4	100	0.4	72	Ntau dua lossis sib npaug li 99	151	0.82×0.84×1.68	0.155
LDR0 13-0.4	130	0.4	96	Ntau dua lossis sib npaug li 99	151	0.82×0.84×1.68	0.165
LDR0 2-0.4	200	0.4	144	Ntau dua lossis sib npaug li 99	151	0.82×0.84×2.1	0.206
LDR{0}}24-0.4/0.7	240	0.4/0.7	174	Ntau dua lossis sib npaug li 99	151/170	0.82×0.84×1.7	0.267
LDR{0}}28-0.4/0.7	280	0.4/0.7	203	Ntau dua lossis sib npaug li 99	151/170	0.82×0.84×1.9	0.302

Nta

1. Ceev ncu tiam

Chav yog tsim sai sai (3-5 feeb) tom qab lub boiler pib, thiab nws ncav cuag kub thiab siab sai

2. High thermal efficiency

(1) Cov yeeb nkab dej ntsug, cov qauv phab ntsa membrane, ua rau thaj chaw nqus cua sov thiab txo cov cua sov, txuag roj

(2) Nruab nrog lub zog txuag, txhim kho thermal efficiency

3. High-end tsis siv neeg tswj qhov system

Lub teb chaws tus qauv hluav taws xob tswj cov khoom siv thiab lub ntiaj teb hom hluav taws xob, tuaj yeem paub txog kev ua haujlwm tsis siv neeg ruaj khov.

4. Kev ruaj ntseg siab

(1) Lub peev xwm dej me me, tsis xav tau kev tshuaj xyuas txhua xyoo

(2) Nruab nrog kev ruaj ntseg interlock ntaus ntawv, xws li dej tsis txaus, overpressure, overtemperature, cua to, lub cev muaj zog overload thiab lwm yam kev tiv thaiv kev ruaj ntseg functions

5. Kev ntseeg siab

(1) Cov khoom siv tag nrho yog tsim raws li tus qauv ntawm chav boiler loj

(2) Cov cuab yeej tiv thaiv kev nyab xeeb: lub siab tswj, lub tshuab xa hluav taws xob, kev nyab xeeb valve, ntsuas ntsuas dej, tswj dej tsis siv neeg, thiab lwm yam.

6. Cov qauv zoo heev

Cov qauv tsim tshwj xeeb, me me thiab siv tau.
