Vertical Coal Fired Chav Boiler

Biomass Chav Generator
Qauv: FTSG (Biomass) Series
Chav Muaj Peev Xwm: FTSH (Biomass) 0.3-1T / H
Chav Siab: 0.7Mpa (xaiv tau raws li qhov xav tau)
Roj: Biomass Particle, Ntoo, Coal
Daim ntaub ntawv: Khaub ncaws ntxhua khaub ncaws thiab Ironing, Biochemical, Khoom noj khoom haus thiab dej haus chav tu, tsev khoom tu, yas ua npuas ncauj, ntoo ua, thiab lwm yam.

Khoom Taw qhia

Product Description

Kev khiav hauj lwm ntawm lub tshuab hluav taws xob yog qhov tsis siv neeg tswj tag nrho, thiab tag nrho cov kev khiav hauj lwm lub xeev tuaj yeem pom meej ntawm lub vijtsam LCD.

Koj tuaj yeem saib xyuas lub xeev ua haujlwm ntawm lub tshuab hluav taws xob, dej theem ntawm lub tshuab hluav taws xob, lub zog siab thiab qis zog, lub xeev khiav ntawm lub twj tso kua mis, lub tswb tsis ua haujlwm, thiab lwm yam. koj tuaj yeem paub lub xeev khiav ntawm lub tshuab hluav taws xob txhua lub sijhawm, thiab siv ntau dua.

Daim duab

c458495626e24bfeb77b7c6ec179727

Khoom zoo

1 Cov qauv ntawm lub cub tawg

Lub tshuab hluav taws xob tshwj xeeb tsim, tuaj yeem hlawv biomass pellet, kuj tuaj yeem hlawv ntoo, orchid charcoal thiab lwm yam roj thaiv.

2 Ceev evaporation

Tom qab lub boiler pib (3-5 feeb), chav yog generated sai sai thiab ncav cuag kub thiab siab ceev.

3 High thermal efficiency

Vertical dej yeeb nkab membrane phab ntsa qauv, nce tshav kub absorbing cheeb tsam, txo tshav kub poob, txuag roj.

4 Humanized tsim

Tsawg pub noj chaw nres nkoj tsim, yooj yim noj, txo kev siv zog ntawm cov neeg ua haujlwm.

5 Kev nyab xeeb siab

(1) Sab hauv dej qis tsim, tsis xav tau daim ntawv pov thawj tshuaj xyuas.

(2) Nruab nrog kev ruaj ntseg interlock ntaus ntawv, xws li dej tsis txaus, overpressure, overtemperature, cua to, lub cev muaj zog overload thiab lwm yam kev tiv thaiv kev ruaj ntseg functions.

6 Kev ntseeg siab

(1) Lub tshuab tag nrho yog tsim raws li tus qauv ntawm chav boiler loj.

(2) Cov cuab yeej tiv thaiv kev nyab xeeb: kev tswj lub siab, lub tshuab xa hluav taws xob, kev nyab xeeb valve, ntsuas siab, tswj tsis siv neeg qib dej, thiab lwm yam.

FTSG Biomass Chav Generator

Qauv	Ratedevaporation muaj peev xwm (t / h)	Rated siab (MPa)	Chav ntsuas kub (℃)	Thermal efficiency (%)	Roj noj (kg / h)	Dimension LxW × H (cm)	Qhov hnyav (t)
FTSG 0.0.3-0.7	0.3	0.7	170	≥93	53	200190270	3.1
FTSG 0.5-0.7	0.5	0.7	170	≥93	66	225250310	4.2
FTSG 0.7-0.7	0.7	0.7	170	≥93	110	265250335	5.6
FTSG1-0.7	1	0.7	170	≥93	155	235310335	6.8

QQ20201124102417

Peb lub tuam txhab

20200713115055ad72e467a8784fd1b2b8a9aa8fb84419

Daim ntawv pov thawj

202007071631279c97b9d8eb7a4fa5bb348412a33d2a41

Neeg tuaj xyuas

Ntim& Kev thauj mus los

FAQ

1. Q. Koj puas yog cov chaw tsim khoom?

A: Yog, peb yog cov chaw tsim khoom ntawm boiler thiab siab hlab ntsha hauv Henan, Suav.

2. Q: Koj puas muaj daim ntawv pov thawj?

A: Yog. Peb lub boiler tau txais Tuam Tshoj GB ISO daim ntawv pov thawj thiab CE daim ntawv pov thawj ntawm EU. Peb kuj tuaj yeem muab ASME, GHOST thiab lwm daim ntawv pov thawj tsim nyog yog tias koj xav tau.

3. Q: Lub sijhawm xa khoom ntawm kab rov tav biomass chav tshuab hluav taws xob?
A: 5-10 hnub ua haujlwm rau ib lub tshuab, thiab 30-40 hnub ua haujlwm rau kev txiav txim ntau thiab qhov rooj rau qhov rooj xa khoom kuj muaj.

4.Q: Dab tsi tsis yog kuv yuav tsum tau muab kom tau txais cov lus tsocai?

Koj yuav zoo dua muab cov kev txwv xws li muaj peev xwm, roj, kev ua haujlwm siab, yog li ntawd rau cov lus qhia ceev thiab meej.

5.Q: Koj puas muab kev pabcuam customized rau koj cov khoom?

Yog lawm, peb tuaj yeem kho lub boiler raws li cov roj, chav muaj peev xwm thiab chav siab xav tau los ntawm cov neeg siv khoom.

Cim npe nrov: Vertical thee raug rho tawm haujlwm steam boiler, Tuam Tshoj, tuam ntxhab, lwm tus muag khoom, Hoobkas, customized, nqe
