Hluav Taws Xob Hluav Taws Xob Hluav Taws Xob Chaw Tsim Tshuaj

Hluav taws xob cua sov Fast Chav Generator
Qauv: LDR (Electric cua sov) Series
Chav Muaj Peev Xwm: LDR (Electric Cua sov) 0.01-0.4T / H
Chav Siab: 0.4 / 0.7Mpa (yeem raws li qhov xav tau)

Khoom Taw qhia

Product Description

1, tsis muaj dej muaj peev xwm ntawm lub tshuab ua kom sov lub cev, ua kom nrawm nrawm, kom tau raws li cov neeg siv khoom xav tau;

2, nyob rau hauv lub Upper ib feem ntawm lub cev ntawm lub loj muaj peev xwm chav chamber thiab dej qab zib dej sib cais ntsuas nyob rau hauv lub lauj kaub, kom ntseeg tau tias high-zoo chav yog muab txhua lub sij hawm;

3, lub tshuab ua kom sov lub cev ua-nyob rau hauv cov khoom siv tiv thaiv dej tsawg heev, txhua lub sijhawm txhawm rau txheeb xyuas cov dej hloov pauv hauv lub tshuab ua kom sov lub cev, kom tsis txhob qhuav hlawv lub cev, kev nyab xeeb kev nyab xeeb;

4, nruab nrog lub siab zoo kev nyab xeeb valve, nres valve, kua theem electrode (Nyiv Omron) lub ntsuas siab thiab lub siab tswj thiab lwm yam khoom siv kev nyab xeeb, kom ntseeg tau tias kev ua haujlwm ruaj khov;

5, nruab nrog cov ntsuas dej zoo, cov dej boiler yog qhov tseeb thiab txheeb xyuas tau;

6, ntsug qauv, compact thiab zoo nkauj, me me hneev taw, elegant zoo, ci xim;

7 Xaiv qhov kev tswj hwm kev ua haujlwm siab, muaj peev xwm tiv thaiv kev cuam tshuam, kev saib xyuas yooj yim, kev nyab xeeb thiab txhim khu kev qha, ua kom lub boiler hauv qhov chaw tsis zoo, kev ua haujlwm ntev

Daim duab

Technical Parameter

LDR Electric Steam Generator

Qauv	Rated evaporation Muaj peev xwm (kg / h)	Rated chav siab (Mpa)	Rated fais fab tuag (kw)	Thermal efficiency (％)	Chav kub (℃)	Dimension (m)	Qhov hnyav (t)
LDR 0.008-0.4	8	0.4	6	≥99	151	0.82×0.84×0.8	0.12
LDR 0.012-0.4	12	0.4	9	≥99	151	0.82×0.84×0.8	0.123
LDR 0.016-0.4	16	0.4	12	≥99	151	0.82×0.84×1	0.139
LDR 0.024-0.4	24	0.4	18	≥99	151	0.82×0.84×1	0.14
LDR 0.032-0.4	32	0.4	24	≥99	151	0.82×0.84×1.2	0.142
LDR 0.065-0.4	65	0.4	48	≥99	151	0.82×0.84×1.4	0.146
LDR 0.075-0.4	75	0.4	54	≥99	151	0.82×0.84×1.4	0.15
LDR 0.1-0.4	100	0.4	72	≥99	151	0.82×0.84×1.68	0.155
LDR 0.13-0.4	130	0.4	96	≥99	151	0.82×0.84×1.68	0.165
LDR 0.2-0.4	200	0.4	144	≥99	151	0.82×0.84×2.1	0.206
LDR0.24-0.4/0.7	240	0.4/0.7	174	≥99	151/170	0.82×0.84×1.7	0.267
LDR0.28-0.4/0.7	280	0.4/0.7	203	≥99	151/170	0.82×0.84×1.9	0.302

Nta

1. Ceev ncu tiam

Chav yog tsim sai sai (3-5 feeb) tom qab lub boiler pib, thiab nws ncav cuag kub thiab siab sai

2. High thermal efficiency

(1) Cov yeeb nkab dej ntsug, cov qauv phab ntsa membrane, ua rau thaj chaw nqus cua sov thiab txo cov cua sov, txuag roj

(2) Nruab nrog lub zog txuag, txhim kho thermal efficiency

3. High-end tsis siv neeg tswj qhov system

Lub teb chaws tus qauv hluav taws xob tswj cov khoom siv thiab lub ntiaj teb hom hluav taws xob, tuaj yeem paub txog kev ua haujlwm tsis siv neeg ruaj khov.

4. Kev ruaj ntseg siab

(1) Lub peev xwm dej me me, tsis xav tau kev tshuaj xyuas txhua xyoo

(2) Nruab nrog kev ruaj ntseg interlock ntaus ntawv, xws li dej tsis txaus, overpressure, overtemperature, cua to, lub cev muaj zog overload thiab lwm yam kev tiv thaiv kev ruaj ntseg functions

5. Kev ntseeg siab

(1) Cov khoom siv tag nrho yog tsim raws li tus qauv ntawm chav boiler loj

(2) Cov cuab yeej tiv thaiv kev nyab xeeb: kev tswj lub siab, lub tshuab xa hluav taws xob, kev nyab xeeb valve, ntsuas qhov siab, qib dej tsis siv neeg tswj, thiab lwm yam.

6. Cov qauv zoo heev

Cov qauv tsim tshwj xeeb, me me thiab siv tau.

Daim ntawv pov thawj
