Tsis tshua muaj siab ua haujlwm siab ua kom muaj hluav taws xob siv hauv tsev

Roj/Gas Fast Steam Generator
Qauv: LSS (Oil / Gas) Series
Chav Muaj Peev Xwm: LSS (Oil / Gas) 0.05-0.5T / H
Chav Siab: 0.4 / 0.7Mpa (yeem raws li qhov xav tau)
Roj: Natural gas, liquefied petroleum gas
Daim ntaub ntawv: Khaub ncaws ntxhua khaub ncaws thiab Ironing, Biochemical, Khoom noj khoom haus thiab dej haus chav tu, tsev khoom tu, yas ua npuas ncauj, ntoo ua, thiab lwm yam.

Khoom Taw qhia

Product Description:

1. LSS hom roj boiler yog ntsug ceev-loading sab hauv combustion peb-rov qab hluav taws tube boiler.

Txais kev tsis ncaj ncees rauv ntub dej rov qab qauv, kub kub flue roj scour lub thib ob thiab thib peb rov qab flue yeeb nkab nyob rau hauv lem, thiab ces tawm mus rau hauv cov huab cua los ntawm lub chimney los ntawm lub back flue chamber, tag nrho cov layout, compact qauv, zoo nkauj tsos.

2, tsim nyog cua sov nto qauv, zoo tswj ntawm flue roj kuj.

3, kev tswj kom tsim nyog ntawm cov pa taws kub, uas yog, kom ntseeg tau tias boiler efficiency, thiab tiv thaiv flue gas condensation, prolong lub neej kev pab cuam ntawm lub boiler.

4, lub boiler yog txawm peem rau nrog ib tug movable pa luam yeeb lub thawv cover, thiaj li hais tias lub boiler txij nkawm yog yooj yim.

5, nruab nrog lub qhov rooj tawg-pov thawj, tsis siv neeg rov qab tom qab siab nyem, kom muaj kev nyab xeeb ntawm boiler.

6. Daim ntawv thov ntawm cov khoom siv hluav taws xob hloov hluav taws xob xws li corrugated rauv thiab threaded pa luam yeeb yeeb nkab tsis tsuas yog ntxiv dag zog rau cov nyhuv hloov tshav kub, tab sis kuj zoo absorbs thermal expansion thiab contraction ntawm lub cub tawg.

Product Details:

Tech Parameter:

LSS Roj/Gas Chav Generator

Qauv	Rated evaporation Muaj peev xwm (kg / h)	Rated chav siab (Mpa)	Thermal efficiency (％)	Chav kub (℃)	Dimension (m)	Qhov hnyav (t)
LSS0.05-0.4/0.7-Y(Q)	50	0.4/0.7	≥93	151/171	0.62×0.62×0.83	0.206
LSS0.1-0.4/0.7-Y(Q)	100	0.4/0.7	≥93	151/171	0.69×0.69×0.968	0.252
LSS0.15-0.4/0.7-Y(Q)	150	0.4/0.7	≥93	151/171	0.75×0.75×1.13	0.303
LSS0.2-0.4/0.7-Y(Q)	200	0.4/0.7	≥93	151/171	0.8×0.8×1.286	0.35
LSS0.3-0.4/0.7-Y(Q)	300	0.4/0.7	≥93	151/171	0.8×0.8×1.525	0.55
LSS0.4-0.4/0.7-Y(Q)	400	0.4/0.7	≥93	151/171	0.84×0.84×1.775	0.7
